● 640×512 Uncooled microbolometer infrared focal plane arrays
● High sensitivity, with clear image
● Dynamic Detail Enhancer (DDE) function; output white hot/black hot/color palette
● Low power consumption, quick start-up, stable performance, image with high uniformity
● Sealed shell, smart shape, nitrogen inside, anti-harsh environment
|
Distance |
Visible light |
1000m |
|
|
Human (1.8m×0.5m) |
Detect |
2910m |
|
|
Recognise |
730m |
||
|
Identificate |
360m |
||
|
Vehicle (2.3m×2.3m) |
Detect |
8320m |
|
|
Recognize |
2080m |
||
|
Identificate |
1040m |
||
|
Detector |
Sensor |
Uncooled infrared focal plane detector(vox) |
|
|
Valid pixels |
640x480 |
||
|
Wave length |
8~14μm |
||
|
NETD |
≤50mK@F1.0,300K |
||
|
Frame |
25Hz |
||
|
Thermal imager |
Focal length |
100mm, 25-100mm 4X zoom, auto focus |
|
|
FOV |
6.2°×5.0° |
||
|
Lens control |
Electronic focus |
||
|
Effect distance |
To people≥2800m, to vehicle≥8000m |
||
|
Control |
Ip software |
||
|
HD 1080P camera |
Effecting Distance |
1000m in daytime |
|
|
Lens |
Focal Length: f=4.5~135mm, 30x optical zooming |
||
|
Lens aperture: F1.6~4.4 |
|||
|
Video Code |
Format: H.264 |
||
|
Video resolution: 1280×1080p(25fps), support dual-stream |
|||
|
Title on screen display: logo, date, time, alarm |
|||
|
Image adjustment: brightness, contrast, saturation |
|||
|
HK series support Hikvision platform |
|||
|
Imaging Components |
1/2.8" Progressive Scan CMOS |
||
|
Pixel: 2.1 MEGA |
|||
|
Low illumination: 0.1 LUX (color), 0.01LUX (black&white) |
|||
|
Network Protocol |
TCP/IP, ARP, ICMP, FTP, RTP/RTCP, NTP, DNS, DDNS, SNMP, PPPoE, RTSP |
||
|
Pan-tilt |
Tilt speed |
0°~30°/s |
|
|
Pan speed |
0°~22°/s |
||
|
Presets |
128 |
||
|
Scan speed |
1 °/s |
||
|
Cruise function |
2 paths |
||
|
Working temperature |
-25℃~+ 60 ℃ |
||
|
Storage temperature |
-40℃~+ 85 ℃ |
||
|
Anti-vibration |
150m/s² 11ms |
||
|
Salt-fog proof |
continuously spray fog for 48 hours under PH6.5-7.2 |
||
|
physics |
Power consumption |
≤30W |
|
|
Weight |
15.5Kg |
||
|
Size |
516.5×240×310mm |
||
|
MTBF |
≥10000hrs |
||
